| Protocols and functionality
|
| Resiliency and high availability
| Fast Reconfiguration of Network Topology (FRNT)
FRNT ring coupling
Multilink dual homing
IEEE 802.1D (STP) and IEEE 802.1w (RSTP)
IEEE 802.1AX/802.3ad Link Aggregation
|
| Layer 2 switching
| IEEE 802.1Q Static VLAN and VLAN Tagging
IEEE 802.3x Flow Control
IGMPv2/v3 snooping
AVT Dynamic VLAN (Adaptive VLAN Trunking)
Management VLAN (Management Interface concept)
Static Multicast MAC filters
|
| Layer 2 QoS
| IEEE 802.1p Class of Service
|
| Layer 2 security
| IEEE 802.1X Port Access Control
MAC Authentication
|
| Manageability
| Management tools
• Web interface (HTTP and HTTPS or CLI (SSHv2 or Telnet)
• SNMPv1/v2c/v3
• Flexible management of configuration and log files
Flexible alarm/event handling system
USB Fluid configuration (Available for products with USB port)
Digital I/O and Flexible alarm/event handling system
Syslog (log files and remote syslog server)
Port Monitoring
SNTP (NTP client)
PPPoE client
DHCP client
DHCP server including option 82
DHCP relay agent including option 82
DDNS
|
| SNMP MIB support
| RFC1213 MIB-2
RFC2863 Interface MIB (ifXTable)
RFC2819 RMON MIB (etherStatsTable)
RFC4188 Bridge MIB
RFC4318 RSTP MIB
RFC4363 Q-BRIDGE MIB
RFC4836 MAU MIB
RFC4133 Entity MIB (entityPhysical)
RFC4319 HDSL2/SHDSL MIB
RFC3433 Entity Sensor MIB
RFC3621 Power Ethernet MIB
WESTERMO PRIVATE MIB
|
